Canon TM-200

Canon TM-200 – New

$3,290.00  (INC GST)   or   Rent From $107.27/month

Want to know more?

Complete the form below for more information!

Please type the characters you see in the box below:
captcha


Description

Specifications in detail
Technology
Printer Type
5 Colour 24″/610mm

Print Technology
Canon Bubblejet on Demand 6 colours integrated type (6 chips per print head x 1 print head)

Print Resolution
2,400 x 1,200 dpi

Number of Nozzles
15,360 nozzles (MBK 5,120 nozzles, Other Colours 2,560 nozzles each)

Line Accuracy
±0.1% or less
User adjustments necessary. Printing environment and media must match those used for the adjustments.

Nozzle Pitch
1,200 dpi (2 lines)

Ink Droplet Size
minimum 5 pl per colour

Ink Capacity
Sales Ink: 130ml/300ml
Bundled Starter Ink: 130ml (Matte Black)/90ml (Black, Cyan, Magenta, Yellow)

Ink Type
Pigment inks – Black, Matte Black, Cyan, Magenta, Yellow

OS Compatability
Microsoft Windows 32 Bit: Windows 7, 8.1, 10
Microsoft Windows 64 Bit: Windows 7, 8.1, 10, Windows Server 2008R2, Windows Server 2012/2012R2, Windows Server 2016
Apple Macintosh: OSX 10.10.5 – OSX 10.11, macOS 10.13

Printer languages
SG Raster (Swift Graphic Raster), HP-GL/2, HP RTL, JPEG (Ver. JFIF 1.02)

Standard Interfaces
USB B Port: Built-in Hi-Speed USB
Ethernet: IEEE 802.3 1-base-T/IEEE 802.3u 100base-TX/IEEE 802.3ab 1000base-T/IEEE 802.3x Full Duplex
Wireless LAN: IEEE802.11n/IEEE802.11g/IEEE802.11b
*Please refer to user manual how to activate/deactivate the wireless LAN

MEMORY
Standard Memory
2 GB

Hard Drive
N/A

PRINTING SPEED
CAD Drawing
Plain Paper (A1 page size)
0:24 (Fast Economy Mode)
0:27 (Fast)
0:42 (Standard)

Poster
Plain Paper (A1 page size)
0:25 (Fast)
0:44 (Standard)

Heavy Coated Paper (A1 page size)
0:55 (Fast)
1:22 (Standard)

Media handling
Media Feed and Output
Roll paper: One Roll, Uppper-loading, Front Output
Cut sheet: Upper-loading, Front Output (Manual feed using media locking lever)

Media Width
Roll paper: 203.2 -610 mm
Cut sheet: 203.2 – 610 mm

Media thickness
Roll/Cut: 0.07 – 0.8 mm

Minimum Printable Length
Roll paper: 203.2 mm
Cut sheet: 279.4 mm

Maximum Printable Length
Roll paper: 18 m (Varies according to the OS and application)
Cut sheet: 1.6 m

Maximum Media Roll Diameter
150 mm

Media Core Size
Internal diameter of roll core: 2″/3″

Margins Recommended area
Roll paper: Top: 20 mm, Bottom: 3 mm, Side: 3 mm
Cut sheet: Top: 20 mm, Bottom: 20 mm, Side: 3 mm

Margins Printable area
Roll paper: Top: 3 mm, Bottom: 3 mm, Side: 3 mm
Roll paper (borderless): Top: 0 mm, Bottom: 0 mm, Side: 0 mm
Cut sheet for Apple AirPrint Only: Top: 3 mm, Bottom: 12.7 mm, Side: 3 mm
Cut sheet for others: Top: 3 mm, Bottom: 20 mm, Side: 3 mm

Media Feed Capacity
Manually switchable by user

Borderless Printing Width (Roll Only)
515mm (JIS B2), 594mm (ISO A1), 10″, 14″, 17″, 24″
[Printable] 257mm (JIS B4), 297mm (ISO A3), 329mm (ISO A3+), 420mm (ISO A2), 8″, 12″, 16″, 20″, 300mm, 500mm, 600mm
*Some environmental conditions may not produce the desired result

Maximum number of delivered prints
Standard position: 1 sheet
Flat position: 20 sheets on A2 landscape (excludes strong curled condition)

DIMENSIONS AND WEIGHT
Physical Dimensions and Weight
Main Unit, Stand and Basket
982 x 887 x 1060 mm (Basket Open)
982 x 757 x 1060 mm (Basket Closed)
52 kg (including Roll Holder Set, excluding ink and print head)

Packaged Dimensions and Weight
Printer (Main unit with pallet): 1152 x 913 x 705 mm, 69 kg
Stand + Basket: 1155 x 824 x 268 mm, 18 kg

POWER AND OPERATING REQUIREMENTS
Power Supply
AC 100-240V (50-60Hz)

Power Consumption
Operation: 69 W or less
Sleep mode: 3.6 W or less
Default setting for the time to enter the Sleep mode: Approx. 5 Minutes
Power off: 0.3 W or less

Operating Environment
Temperature: 15-30?,
Humidity: 10-80% RH (no dew condensation)

Accoustic Noise (Power/Pressure)
Operation: 44 dB (A) (Plain paper, line drawing, standard mode)
Standby: 35 dB (A) or less
Operation: 6.0 Bels (Plain paper, line drawing, standard mode) (Measured on ISO 7779 standard)

Regulations
Europe: CE mark, Russia: EAC

Certificates
TUV, CB

WHAT’S INCLUDED
What’s in the box?
Printer, 1 x print head, 3-inch paper core attachment, Power Cable, UK Power cord (240V,3P), 1 set of starter ink tanks, Set up guide, Safety/Standard Environment leaflet
User software CD-ROM (Win)
PosterArtist Lite CD-ROM, EU Biocide Sheet, Eurasian Economic Union Sheet, Important Information Sheet

Software Included
imagePROGRAF TM-Series Printer Driver, Print Plug-In for Office, Quick Utility Toolbox and PosterArtist Lite
Other software available as Download from Web

OPTIONS
Optional Items
Printer Stand: SD-23
2/3″ Roll Holder: RH2-28

CONSUMABLES
User Replaceable Items
Ink Tank: PFl-120 (130ml), PFl-320 (300ml)
Print Head: PF-06
Cutter Blade: CT-08
Maintenance Cartridge: MC-31
